CC9074DK Deep Cut Saw

CC9074DK Deep Cut Saw with powerful jackshaft drive with low speed, high torque blade drive maximizing full engine powerFeatures & Benefits:
Tier 4 Final Kubota diesel engine
Advanced digital 7″ display with engine service alerts and maintenance reminders
Front view camera to view sawing location and obstructions
LED spot and bar lights for night sawing
Auto Water System (AWS) automatically starts/stops water to the blade when in and out of the cut
Undercarriage slurry flap to minimize slurry buildup on rear axle components
Effective weight balance for optimum performance
Fast attach blade guard stabilizer with quick disconnect ball joints to speed guard removal
East-turn 5th wheel that automatically lifts rear wheels at max raise the height to allow rear saw swivel
Enclosed rear wheel motors that are hydraulically driven with center swivel for easy tracking adjustment
SImple freewheeling with dash mounted switch activation
Robust blade shaft with massive support by 3 pillow black style spherical roller bearings
Powerful jackshaft drive with low speed, high torque blade drive maximizing full engine power
Advance air cleaner with redial seal primary and secondary filters along with spinner style pre-cleaner
Robust radiator core made of heavy-duty aluminum that withstands frequent power washing
Sealed electronic protection that resists heat, moisture, shock, and vibration
SIngle piece frame platform with heavy bar and tubular reinforcement

Blade Capacity
Engine/Motor Make
Part Number
Catalog Number

36″
Kubota®
5801290
68055

42″
Kubota®
5801291
68247

48″
Kubota®
5801292
57696

54″
Kubota®
5801293
46758

60″
Kubota®
5801294
59724
